P1 Engine Case Thru-Bolt Kit for Porsche 914 912E VW Type 2/4
sku: 204-01

P1 Engine Case Thru-Bolt Kit for Porsche 914 912E VW Type 2/4

$299.00

LN Engineering / Aircooled Technology exclusive Point One VW Type 2/4 and Porsche 914 912E Engine Case Through Bolt Kit. Includes 6 studs, 12 nuts and washers, and lube. Designed as a direct replacement for the factory through bolts and does not require any modifications to the crankcase and is recommended for all performance engine builds.

in , , , , , , , Brand:

Description

P1 Engine Case Thru-Bolt Kit for Porsche 914 912E VW Type 2/4

Instructions and Specifications

Instructions
  1. Disregard the plastic spacers found on stock crankcase through bolts. Note: the original purpose of the plastic spacers was to simplify assembly during mass production by holding the bolts in place for assembly workers, so their removal will not compromise function or performance.
  2. After assembling the bottom end of the engine, but before applying curing sealants to crankcase halves and putting them together, prep the studs by applying the supplied moly-lube to the threads on both ends of each stud and a non-hardening sealant such as Hylomar or Curil-T on both sides of the supplied washers.
  3. Go ahead and put one nut and washer on each stud. Have them lying out ready to put in place as soon as the crankcase halves go together.
  4. As time is of the essence, immediately after applying sealant to the crankcase halves and putting them together, install the studs, washers, and nuts as normal. The nuts fit either a 12-point 7/16” or 12-point 11mm socket.
  5. Quickly tighten each nut to 20 ft-lb in the following sequence:
    4 2 6
    5 1 3
  6. Tighten the two bolts surrounding the #4 main bearing to the factory setting.
  7. Tighten the remaining bolts all around the crankcase to their factory
    settings.
  8. Now that you can slow down once again, go back and retighten the six studs to 32 ft-lb in the same sequence.
  9. Tighten nuts to final torque spec of 36 ft-lb again using the same sequence.
  10. Repeat above step to ensure that all nuts received the proper preload.
  11. Wipe off excess moly lube on studs.

Specifications

Your case studs are designed to the highest standards and manufactured by P1. The threads on the studs are 3/8”-24. The use of studs instead of bolts does not create a performance compromise, but does add flexibility to disassembly procedures by allowing them to be removed from either side of the engine – a trait very useful when only disassembling half of the engine for a repair.

Cross Reference: 021101145B, RWE-7001

Fits: Porsche 914 912E / VW Type 4

Important: Before ordering, always confirm that the part fits your specific type/model/engine.

Additional information

Weight 5 lbs
